Automated Guided Vehicles

Auriga Counter balanced Laser guided vehicles

Auriga Counter balanced | © OCME

Auriga CT are counterbalanced vehicles with forks. These vehicles are designed for transporting any type of product.

Auriga Counter balanced | © OCME
HIGH STABILITY OF THE PRODUCT BEING MOVED
POSSIBILITY OF HANDLING PALLETS, HALF PALLETS AND QUARTERS OF A PALLET

product benefits

PALLET HANDLING

The Auriga 20 CT - 30 CT - 45 CT models are usually used to handle multiple pallets simultaneously.

FLEXIBILITY

Since they are counterbalanced, these machines are flexible and able to move any type of product, from any loading or unloading station.

overview

The Auriga CT range begins with the smaller model, Auriga 8CT, ideal to move in reduced spaces with load capacity of 800 kg, up to larger models,
such as Auriga 45 CT, used to transport 3 pallets with maximum load capacity of 4.500 kg.

option & data sheet

WAREHOUSE MANAGEMENT SYSTEM (WMS)

Integrated warehouse management is obtained thanks to algorithms which are capable of making the correct choices to exploit all the available space. The AGV Manager guides the vehicles on specific missions based on the load they need to load or unload according to various parameters.

WAREHOUSE MANAGEMENT SYSTEM (WMS) | © OCME

The network

The Ethernet network used for the systems designed by OCME is designed by highly qualified specialised technicians, capable of guaranteeing perfect operation and maximum availability of the infrastructure. The network, which is part wired, and part wireless, is designed for the LGVs to liaise with the central traffic management system and concurrently assess the requests originating from the operators (via normal handheld devices), from palletisers/depalletisers or in general from any other plant, irrespective of the language and of the communication protocol used.

The network | © OCME

Supervisor

The supervision system is designed to manage missions, criteria for the dynamic allocation of vehicles. It is interconnected with the other company devices, such as PC, PLC, database and ERP systems its purpose is to define, monitor, forecast and archive all the information relating to the logistics system devices, especially Auriga laser guided vehicles. Thanks to an entirely visual interface, an overall representation of the plant can be seen with the location of the vehicles and the related load. The status of every vehicle can be seen in order to check its operating parameters.

Supervisor | © OCME

Battery replacement or charging systems.

The battery replacement or charging system is designed to guarantee the wide autonomy for Auriga vehicles. There are three types: ad hoc charging, semi/automatic battery replacement or automatic battery replacement. Every vehicle has a charge indicator on-board managed by the microprocessor that liaises with the AGV Manager, keeping it constantly updated as to the status of the charge and consequently the need to refuel.

Battery replacement or charging systems. | © OCME

SPECIFICATIONS   AURIGA 8 CT AURIGA 15 CT AURIGA 20 CT AURIGA 30 CT AURIGA 45 CT
Max unit Load Weight (kg)   800 1500 2000 3000 4500
LGV Height* (mm)   3000 3000 3000 3000 3000
Lifting height* (mm)   3000

3000

3000

3000

3000

Max Height Lift Mast (mm)   1200 1200 1200 1200 1200
LGV Length (mm)   2550 3050 3650 4000 4350
LGV Width* (mm)   820 1000 1600 1600 1800
Wheel base (mm)   920 1150 1080 1500 1850
Max. speed (mm/s)   1700 1700 1700 1700 1700
Max speed Fork Lift (mm/s)   150 200 200 200 200
LGV weight
with battery (Kg)
  2000 3800 6000 8000 10000
*Customizable
