Automated Guided Vehicles

Auriga Shuttle Rack Laser guided vehicles that manage shuttle

Auriga Shuttle Rack | © OCME

The Auriga Shuttle Rack is a highly precise forklift vehicle capable of reaching warehouse heights up to 12 metres.

Auriga Shuttle Rack | © OCME
LOAD HANDLING BETWEEN SHELVING PLACED AT A DISTANCE OF 3300 mm
HIGH LOAD CAPACITY IN HEIGHT

product benefits

It works at significant heights

(up to 12 meters)

Extreme precision even during shuttle handling

overview

The forks are self-centring thanks to a patented tilting system by OCME.
The machine, in addition to handling materials on pallets, interacts with the shuttles of automatic warehouses guaranteeing a high level of storage and full traceability of the presence of material.
The vehicle also ensures a perfect management and handling of materials to/from the production line, and supervision of the shipment areas.

option & data sheet

Battery replacement or charging systems.

The battery replacement or charging system is designed to guarantee the wide autonomy for Auriga vehicles. There are three types: ad hoc charging, semi/automatic battery replacement or automatic battery replacement. Every vehicle has a charge indicator on-board managed by the microprocessor that liaises with the AGV Manager, keeping it constantly updated as to the status of the charge and consequently the need to refuel.

Battery replacement or charging systems. | © OCME

Supervisor

The supervision system is designed to manage missions, criteria for the dynamic allocation of vehicles. It is interconnected with the other company devices, such as PC, PLC, database and ERP systems its purpose is to define, monitor, forecast and archive all the information relating to the logistics system devices, especially Auriga laser guided vehicles. Thanks to an entirely visual interface, an overall representation of the plant can be seen with the location of the vehicles and the related load. The status of every vehicle can be seen in order to check its operating parameters.

Supervisor | © OCME

The network

The Ethernet network used for the systems designed by OCME is designed by highly qualified specialised technicians, capable of guaranteeing perfect operation and maximum availability of the infrastructure. The network, which is part wired, and part wireless, is designed for the LGVs to liaise with the central traffic management system and concurrently assess the requests originating from the operators (via normal handheld devices), from palletisers/depalletisers or in general from any other plant, irrespective of the language and of the communication protocol used.

The network | © OCME

WAREHOUSE MANAGEMENT SYSTEM (WMS)

Integrated warehouse management is obtained thanks to algorithms which are capable of making the correct choices to exploit all the available space. The AGV Manager guides the vehicles on specific missions based on the load they need to load or unload according to various parameters.

WAREHOUSE MANAGEMENT SYSTEM (WMS) | © OCME

SPECIFICATIONS   AURIGA SHUTTLE RACK
Max unit Load Weight (kg)   from 1400 to 500
LGV Height* (mm)   5500
Lifting height* (mm)   12000
Max height lift mast* (mm)   12830
Fork length* (mm)   1000
LGV Length (mm)   3025
LGV Width* (mm)   1600
Wheel base (mm)   1470
Max. speed (mm/s)   1700
Max speed Fork Lift (mm/s)   400
LGV weight
with battery (Kg)
  6200
*Customizable



technical sheet

download

brochure

download

case studies

THE OCME LGVs SYSTEM  JOINS VIOLETA
Case studies
THE OCME LGVs SYSTEM JOINS VIOLETA

The company decided to rely on OCME's automatic solutions, to improve the performance of its warehouse and the working environment. The answer given by OCME in order to meet the needs of the industrial lay-out was providing two Auriga high-precision LGV lift trucks
