Robot S7 Self propelled robot for stretch wrapping
Thanks to the experience gained over time, Robopac presents a new range of self-propelled packaging machines, Robot S7. The use of advanced technologies and of the utmost attention to safety systems represents the essence of the developing capacity of Robopac. The machine is provided with a high level of packaging autonomy and great work flexibility and built to wrap and stabilize palletized loads of any shape, size and weight, using stretch film. Thanks to the innovative system for facilitated film insertion (ILS) through the opening of the carriage and to the Power Drive technology with brushless motorization, it is possible to control the film with extreme precision, guaranteeing perfect pre-stretching and the lowest consumption of film and energy in view of environmental sustainability.
read more
product benefits
DETAILS
FRD CARRIAGE
Film carriage with mechanical brake manually adjustable to set the film tensioning. Brake engagement- release device to facilitate hooking the film to the base of the pallet.
FR CARRIAGE
Film carriage with electromagnetic powder brake on return roller, stretch tension adjustable from control panel.
P3GS CARRIAGE
The P3GS pre-stretch carriage has a motorized pre-stretch with 3 selectable fixed ratios (0% -230% -300% std and 0% -150% -250% opt.)
PVS CARRIAGE
Carriage with powered stretch system controlled by two independent motors. Stretch ratio adjustable from panel board from 0% up to 500% .
CONTROL PANEL
The control panel with color touch screen allows you to create up to 12 programs (+12 with Cube Technology) in a simple and intuitive way thanks to the patented Robopac icons.
overview
Discover more on our app Robopac HMI
Try the Rotoplat, Masteplat Plus & Robot S7 user friendly control panel on your devices.
Robot S7
option & data sheet
R-Connect
Innovation and connection for customer service: the tranquillity of maximum productivity as a result of constant monitoring of proper machine operation.
Powerful, plug & play and user friendly, R-Connect is a “turnkey” system for the end-user: the main advantage is total “peace of mind”, which is absolute tranquillity regarding machine operation, which includes production performance verification and optimisation of all management costs.
In fact, the system minimises machine downtime and manages maintenance operations better, also providing an immediate troubleshooting procedure, until the full and remote upgrade of the machine’s management software is completed.
Lithium battery
Easily movable battery thanks to the weight of less than 15 kg.
Battery indispensable in the case of continuous use of ROBOT S7, or when it is not possible to use the whole night or sacrifice a work shift for recharging.
It is possible to charge this battery frequently for short periods.
This lithium battery can be charged in any environment, it is not necessary to have a recharging area: this is because during recharging this battery does not release any gas into the air.
MECHANICAL ROPING DEVICE ADJUSTABLE FROM TOP OR BOTTOM
Automatic film band reduction system.
The best solution for containing the product.
Selectable from top or bottom.
Technical features
| ROBOT S7 FRD | ROBOT S7 FR | ROBOT S7 P3GS | ROBOT S7 PVS | ||
| n° of pallets per battery charge | >250 (Pb/Acid) | >250 (Pb/Acid) | >250 (Pb/Acid) | >250 (Pb/Acid) | |
| batteries | N°2 12 V 90 Ah Pb/Acid (std.) N°1 24 V 50 Ah Lithium (opt.) |
N°2 12 V 90 Ah Pb/Acid (std.) N°1 24 V 50 Ah Lithium (opt.) |
N°2 12 V 90 Ah Pb/Acid (std.) N°1 24 V 50 Ah Lithium (opt.) |
N°2 12 V 90 Ah Pb/Acid (std.) N°1 24 V 50 Ah Lithium (opt.) |
|
| maximum product height | mm | 2200 std. 2400/2800 opt. |
2200 std. 2400/2800 opt. |
2200 std. 2400/2800/3100 opt. |
2200 std. 2400/2800/3100 opt. |
| minimum dimensions (LxW) | mm | 600x600 |
600x600 |
600x600 |
600x600 |
| film carriage type | FRD | FR | P3GS | PVS | |
| film stretch | manual | adjustable from panel |
adjustable from panel |
adjustable from panel |
|
| film pre-stretch | n.a. | n.a. | 0% - 230 % - 300 % (std.) 0% - 150% - 250% (opt.) |
variable 0-500% | |
| power supply voltage | V | 100-240 V (1Ph) 50/60Hz | 100-240 V (1Ph) 50/60Hz | 100-240 V (1Ph) 50/60Hz | 100-240 V (1Ph) 50/60Hz |
| machine rotation speed | m/min | 35÷80 | 35÷80 | 35÷80 | 35÷80 |
| carriage up-down speed | m/min | 1,5 ÷ 5 | 1,5 ÷ 5 | 1,5 ÷ 5 | 1,5 ÷ 5 |
| maximum reel dimensions (HxØ) | mm | 500x300 | 500x300 | 500x300 | 500x300 |
| maximum reel weight | kg | 20 | 20 | 20 | 20 |
| film thickness | μm | 7÷35 | 7÷35 | 7÷35 | 7÷35 |
