Stretch wrapping

ROBOBAND 1VH Fully automatic horizontal bander with 1 film band

Name: ROBOBAND 1VH Fully automatic horizontal bander with 1 film band
Brand: robopac

Automatic end-of-line machine for the application of a stretch film band for labelling purposes.

produced by

OUTPUT CAPACITY UP TO 150 P/H

SINGLE PAIR OF REELS

ADJUSTABLE SEALING

product benefits

PARTIAL BANDING

Suited to applications where is needed to secure a stack of products not requiring an overall containment

PRE-LABELLING

Possibility to add a labelling machine for product identification

FULLY AUTOMATIC MOVEMENTS

High precision movements controlled by PLC

QUICK AND FLEXIBLE SETUP

Quick and easy replacement of most components

STANDARD EQUIPMENTS

MFDS - PRE-STRETCH CARRIAGES

Motor-driven carriage controlled by clutch for unstable loads.

overview

Fully automatic banding machine particularly suitable for applications where label application on the product is very challenging due to product shape.

ROBOBAND Fully automatic horizontal banding machine.

Pallet dimensions min - max	mm	600x800 - 1300x1100	inches	24x32 - 52x44
Maximum pallet height	mm	2000	inches	80
Height of the supply line	mm	250 - 550	inches	10 - 22

Standard power supply voltage and frequency	V - Hz	400-415 ± 5% - 50 ± 1%
Optional power supply voltage and frequency	V - Hz	380-480 ± 5% - 60 ± 1%

Compressed air pressure

Bar

6 ± 1

Film reel height	mm	100 - 500		inches	4 - 20
Max reel diameter	mm	500		inches	20

brochure

download

case studies

Case studies

PLZENSKY PRAZDROJ

Plzensky Prazdroj, another leading company that has chosen Robopac to modernise its packaging systems at the various manufacturing sites in the Czech Republic and Slovakia.

More info
